EGW Handgun Pistol Mount for Leupold Deltapoint Pro, Jpoint, and US Optics MCRS Red Dot Sights

$89.95 inc. GST

SKU: N/A Category: Brand:

Simply remove the rear sight on your pistol and replace it with the EGW mount in order to mount your Leupold Deltapoint Pro, Redfield Accelerator, Optima, Shield RMS/RMSC/SMS/Jpoint, or US Optics MCRS red-dot sight.

No alterations are required. You can take our mount off and replace your rear sight at any time. Mounting hardware included.

  • Made in the USA
  • 7075 T6 Aircraft grade aluminium
  • Black models are Type 3 hard coat anodized
  • Mounting screws included

Our red dot sights are meant to be installed from the left to the right (with the muzzle facing forward). The dovetail has a progressive taper to allow for easier install.

Installation: EGW recommends 15 inch lbs of torque and a drip of blue loctite.

Rear sight pusher tool recommended for installation.

Notes:

Walther PPQ 22LR 49390: This mount fits the Walther PPQ .22LR.

This mount does not fit: Walther PPQ 22, Walther PPQ Q4 Tac, Walther Q5 Match.

The PPQ sight has a hole drilled in the bottom of the dovetail to accomodate the plunger on some models of the Walthers. This plunger may also be removed from the slide if desired.

SIG 220 10mm HUNTER 49392: This mount fits: Sig P220 10mm Hunter, Sig P220 Super Match SAO, Sig P220 Match Elite (with adjustable sights).

Walther PPQ 49394: This mount fits the following Walther models: PPQ Classic (M1), PPQ M2 (All Models), PPQ 45, PPQ 45 SD, PPQ Sub Compact, P99 (All Models), PPX (All Models), Creed, Creed 10 Round, PPS (All Models), PPS M2 (All Models).

This mount does not fit: Walther PPQ 22, PPQ Q4 Tac, Q5 Match

The PPQ sight has a hole drilled in the bottom of the dovetail to accommodate the plunger on some models of the Walthers. This plunger may also be removed from the slide if desired.

S&W 1911 ADJ SIGHTS 49395: Will fit S&W 1911 with Adjustable Rear Sights, will not fit models with fixed rear sights.

DESERT EAGLE (POST 2017) 49396: Please take note of the Pre 2017 and Post 2017 differences before placing your order: Pre 2017 rear shelf behind the dovetail is .187″. Post 2017 rear shelf behind the dovetail is .120″

CZ 75 SP-01 Shadow 49397: This mount fits: CZ 75 Shadow, CZ 75 SP01 Shadow, CZ Shadow 2

Sig P210A Target 49398: This mount fits: Sig P210A Target

This mount for the P210 is made specifically for the U.S. made P210s. The front of the mount will need to be cross drilled to fit each individual gun. The pin from the factory rear sight may be reused as well.

The hole dimension for the cross hole is 2.04mm. There are 2.04mm drill bits available from sites like Grainger, but you may also be able to use a 5/64″ bit to mark the hole on the mount and a 3/32″ bit to drill the hole. Sig uses a 2mm coiled spring pin to hold the original sight in place.

*For this mount to work with the Holosun 407K and 507K, the rear pins on the mount MUST be removed by milling or filing.

MARLIN 1894 49399: This mount is comes with both #6 and #8 screws and is drilled to suit both screw sizes.

This mount fits: Marlin 1894, 1895, Henry H009, H010, H014, H006, H012 Golden Boy, Camp Carbine 9mm, Camp Carbine 45, Ruger PC Carbine.

S&W 1911 FIXED SIGHTS 49400: Will fit S&W 1911 with Fixed Rear Sights, will not fit models with adjustable rear sights.

S&W M&P 22 COMPACT 49401: Using this mount in combination with a red dot sight will increase the weight on the slide of your firearm. This may lead to cycling issues especially in .22s.

CZ 75 49402: This mount fits the following CZ models: 75, 75 SP-01, 75 SP-01 Phantom, 85, P-01, PCR.

This mount does not fit the CZ P-07 or CZ P-09

(Does NOT fit any of the SP-01 Shadow variants)

LPA LOW MOUNT 49403: This mount fits: Baby Desert Eagle (Post 2006),
EAA Witness Elite Match.

DESERT EAGLE (PRE 2017) 49405: Please take note of the Pre 2017 and Post 2017 differences before placing your order: Pre 2017 rear shelf behind the dovetail is .187″. Post 2017 rear shelf behind the dovetail is .120″

H&K USP 49406: DOES NOT FIT THE USP COMPACT. The USP Compact rear sight cut depth is .200″, The standard USP (for this rear sight cut) rear sight cut depth is .160″

This mount fits: USP Tactical 9mm, USP Tactical .45 ACP, USP 9mm, USP 40 S&W, USP .45 ACP.

Does NOT Fit: USP Expert, USP Elite.

EAA SS, TANFOGLIO WITNESS 49407: This mount fits: EAA / Tanfoglio Witness with adjustable rear sight (windage AND elevation).

This mount does not fit: EAA / Tanfoglio Witness with fixed rear sight

NOVAK 49410: This mount will fit pistols with a Novak Cut rear sight mount such as STI fixed rear sights, Springfield Armoury 1911, GSG 1911, Rock Island, Iver Johnson, and Wilson Combat. CHECK YOUR PISTOL HAS A NOVAK CUT SIGHT BEFORE ORDERING.

Minor modification to the sight base may be necessary for Rock Islands and GSG 1911 .22s.

KIMBER and RUGER 1911 49412: This mount fits: Kimber 1911 (with  adjustable rear sights for windage and elevation), Ruger SR1911 (with adjustable rear sights for windage and elevation). Will not fit models with fixed rear sights.

LPA 49413: This mount will fit pistols with an LPA Cut rear sight mount such as Sig Sauer 1911, STI adjustable rear sights, Springfield Armoury, Rock Island, Iver Johnson, CHECK YOUR PISTOL HAS A LPA CUT SIGHT BEFORE ORDERING.

Will Not Fit: Para Elite LS Hunter, Remington R1 10mm Hunter

GLOCK 49414: This mount fits all generation Glocks: 17, 19, 20, 21, 22, 23, 24, 26, 27, 29, 30, 31, 32, 33, 34, 35, 36, 37, 38, 39, 41, 42, 43, 46, as well as the Canik TP9SF, Bersa BP9CC, Tactical Solutions .22lr Conversion, Advantage Arms .22lr Conversion

Does not fit the following Glock MOS models: Glock 17 Gen 4 MOS, Glock 19 Gen 4 MOS, Glock 34 Gen 4 MOS, Glock 40 Gen 4 MOS, Glock 41 Gen 4 MOS, Glock 35 Gen 4 MOS, Glock 34 Gen 5 MOS.

SIG SAUER 49415: THIS MOUNT DOES NOT WORK WITH ANY SIG OPTICS READY PISTOLS (P320 X-CARRY ETC.)

This mount fits (including but not limited to): Sig #8 Sights, P220, P224, P225, P225-A1, P226, P227, P228, P229, P238, P239, P245, P320, P938, SP2022, M11-A1, MK25, Bersa Thunder UC Series (9/40/45), Bersa Thunder HC Series (9/40/45), FN 509.

This mount does not fit: Sig 1911s, Any Optics Ready Sigs i.e. P226 Legion RX, P229 RX, P320 X-Carry etc., P210 Target, P365, FN 509 Tactical.

S&W 52 49416: This mount fits: Smith & Wesson Model 52

This mount does not fit: Smith & Wesson Model 41

S&W REVOLVERS 49417: This mount will fit K, L, N, and X frame Smith & Wesson Revolvers.

If your revolver is not drilled and tapped this mount will not work. The best way to verify that it is/is not drilled and tapped is to open the cylinder and check the rib underneath. There should be through holes that are drilled and tapped. If there are not this mount will not work without you having the gun drilled and tapped.

RUGER REVOLVER 49418: This mount fits the following Ruger Revolvers: Blackhawk, Redhawk, GP100 (with adjustable rear sights), GP100 Match Champion.

This mount does not fit: Ruger Flattop Revolvers

BOMAR 49419: This mount will fit pistols with a Bomar Cut rear sight mount such as the STI Edge (Bomar Cut Version), Les Baer 1911 (adjustable rear sights), Colt Gold Cup Trophy with Bomar Rear Sight Cut, Colt Gold Cup National Match .45acp, Colt Gold Cup National Match 9mm, Springfield TRP Operator.  CHECK YOUR PISTOL HAS A BOMAR CUT SIGHT BEFORE ORDERING.

RUGER AUTO 49420: This mount fits the following Ruger pistols: Ruger MK I, MK II, MK III, MK IV, P85, P89, P90-95, P97, 22/45

COLT GOLD CUP 49421: This mount fits the following Colt models: Gold Cup,
Trooper Mark 3, Python, Anaconda.

This is for Colt models with the Elliason style adjustable rear sight. The elevation screw from the original rear sight is re-used in the center hole on this mount.

GI 1911 49423: This mount will fit: 1911s with a G.I. style rear sight cut, and the following Iver Johnson firearms 1911A1, 1911A1 9, Falcon 45, Thrasher 45, Thrasher 9, 1911A1 Chrome 38W, 1911A1 Chrome 38P, 1911A1 CHRW45, 1911A1 CHR45P, 1911A1 CHR45WP, 1911A1 Zombie, 1911A1 Copperhead, 1911A1 Water Moccasin, 1911A1 Boa, 1911A1 Muddy Girl 9mm, 1911A1 Digital Navy, 1911A1 Digital Snow 45acp.

SPRINGFIELD XD 49424: This mount fits the following Springfield XD models: XD MOD.2 – 3″ SUB-COMPACT MODEL, XD MOD.2 – 3.3″ SUB-COMPACT MODEL, XD MOD.2 – 4″ SERVICE MODEL, XD MOD.2 – 4″ SERVICE MODEL THREADED BARREL, XD MOD.2 – 5″ TACTICAL MODEL, XD 3″ SUB-COMPACT MODEL, XD 4″ SERVICE MODEL, XD(M) 3.8″ COMPACT MODEL, XD(M) 3.8″ MODEL, XD(M) 4.5″ MODEL, XD(M) 4.5″ THREADED BARREL MODEL, XD(M) 4.5″ OSP FULL SIZE, XD-S 3.3″ MODEL, XD-E 3.3″ SINGLE STACK

It does not fit: XD(M) 5.25″ COMPETITION SERIES MODEL

Universal 0.468 RAD 49425: This mount has a bottom radius of .468″. There should be a slight gap at the top of the radius between the receiver and the mount when mounted. The two spreads on this mount measure .500″-.505″ and .8625″. This should fit barrel/receiver diameters from .936″-1.350″.

UNIVERSAL 0.670 RAD 49426: This mount has a bottom radius of .670″. There should be a slight gap at the top of the radius between the receiver and the mount when mounted.

Note that this mount is drilled for and only includes #6 screws. If your application requires #8 screws then you will need to source these screws yourself as well as have this mount drilled to suit #8 size screws.

The two spreads on this mount measure .500″-.505″ and .8625″ which should fit the receiver ring on the following guns:

Shotgun: Mossberg 500, 590, 835, 930, 935 Pre ’97, Mossberg 500, 590, 835, 930, 935 Late (after ’97) (Requires 8-40 and Longer Screws), Benelli Auto / Super Black Eagle / Vinchi, M2 (Will Work in the Front Set Only, 8-40 Screws), Benelli Supernova (Will Work in the Front Set Only, 8-40 AND Longer Screws), Browning A-Bolt 12 Gauge, Savage 210, Savage 212, Savage 220, Stoeger M3000 / Stoeger M3500 (Will Work in the Front Set Only, 8-40 Screws), Winchester 1300, Winchester SXP

Rifle: Remington 700, 722, 40x, Remington 783, Remington 710/770, Remington xp 100, Remington 4, 6, 7400, 7615 (Front Set Only, 8-40 Screws), Savage Arms Centerfire Models, Winchester 70.

S&W M&P 49427: This mount will fit: Smith & Wesson M&P Full Size, 2.0 Full Size, 22 Full Size, Compact, 2.0 Compact, SD9VE, SD40VE.

This mount does not fit: Smith & Wesson M&P Shield, Shield EZ .380, SW9VE, SW40VE, C.O.R.E Series, M&P .22 Compact.

Smith and Wesson’s rear sight dovetails are known to vary in dimensions. Our sights are made to the same tolerances. Some users may have trouble installing our plate on their slide due to the varying tolerances in your slides. Please keep this in mind when ordering. Our return policy does allow for returns of unused and undamaged parts. These mounts should be installed and checked by a qualified gunsmith. No liability is expressed or implied for damage or injury which may result from improper installation or use of this product.

FN, FNS, FNX 49428: This mount does not fit the FN Five-seveN (5.7)



Available for the following:

#49390: Walther PPQ 22LR

#49392: Sig Sauer 220 10mm Hunter

#49393: CZ P-10 C

#49394: Walther PPQ M2

#49395: S&W 1911 with Adjustable Rear Sights

#49396: Desert Eagle (Post 2017)

#49397: CZ 75 SP-01 Shadow and Shadow 2

#49398: Sig Sauer P210A Target

#49399: Marlin 1894, 1895, Henry H009, H010

#49400: S&W 1911 with Fixed Rear Sights

#49401: S&W M&P 22 Compact

#49402: CZ 75, 75 SP-01, SP-01 Phantom, 85, P01, and PCR (Does NOT fit SP-01 Shadow variants)

#49403: LPA Low Mount Cut Rear Sight

#49404: Colt 1911/22 Rail Gun with the Walther Slide

#49405: Desert Eagle (Pre 2017)

#49406: H&K USP

#49407: EAA Super Sight, Tanfoglio Witness with Adjustable Rear Sight

#49408: H&K VP9, VP9SK, VP40, P30, P30L, P30SK, HK45, HK45C

#49410: Novak Cut Rear Sight

#49411: Kimber 1911 with Fixed Rear Sights

#49412: Kimber 1911 and Ruger SR1911 with Adjustable Rear Sights

#49413: LPA Cut Rear Sight

#49414: Glock

#49415: Sig Sauer P220-229, 320

#49416: S&W 52

#49417: S&W Revolvers, K, L, N and X Frames

#49418: Ruger Revolvers

#49419: Bomar Cut Rear Sight

#49420: Ruger Auto (Mk 1, Mk 2, Mk 3, Mk 4, P85, P89, P90-95, P97, 22/45)

#49421: Colt Gold Cup, Python, Anaconda

#49423: 1911 with GI Style Cut Rear Sight

#49424: Springfield XD

#49425: Universal Fit for 0.468″ Radius for Rifles and Shotguns

#49426: Universal Fit for 0.670″ Radius for Rifles and Shotguns

#49427: S&W M&P

#49428: FN, FNS, FNX



ATP is an authorised Australian dealer for EGW. All EGW products bought from ATP are covered by EGW’s Australian Warranty.

Weight 0.101 kg
Part Number

#49390 Walther PPQ 22LR, #49392 Sig 220 10mm Hunter, #49393 CZ P-10 C, #49394 Walther PPQ M2, #49395 S&W 1911 Adj Sights, #49396 Desert Eagle Post 2017, #49397 CZ 75 SP-01 Shadow, #49398 Sig P210A Target, #49399 Marlin 1894, 1895, Henry H009, #49400 S&W 1911 w Fixed Sights, #49401 S&W M&P 22 Compact, #49402 CZ 75, Phantom, P01, P07, #49403 LPA Low Mount Cut, #49404 Colt 1911/22 RG Walther, #49405 Desert Eagle Pre 2017, #49406 H&K USP, #49407 EAA, Tanfoglio Witness, #49408 H&K VP9, VP9SK, VP40, #49410 Novak Cut Rear Sight, #49411 Kimber 1911 Fixed Sights, #49412 Kimber 1911 Adj Sights, #49413 LPA Cut Rear Sight, #49414 Glock, #49415 Sig Sauer P220-229, 320, #49416 S&W 52, #49417 S&W Revolvers, K, L, N, X, #49418 Ruger Revolvers, #49419 Bomar Cut Rear Sight, #49420 Ruger Mk 1, 2, 3, 4, 22/45, #49421 Colt Gold Cup, Python, #49423 1911 GI Cut Rear Sight, #49424 Springfield XD, #49425 Universal Fit for 0.468 Radius, #49426 Universal Fit for 0.670" Radius, #49427 S&W M&P, #49428 FN, FNS, FNX
